Mainly used for ceiling fan light and etc workpiece do whole balance,take full consideration of whole component's balancing accuracy,to eliminate the unbalance amount caused by the bearings,other parts and assembly errors.Improve products'quality
Well designed mechanical module allowed fast and accurate balance rotor.you will have a greater choice.Use less money to choose a best balancing equipment
This balancing machine adopts soft bearing bracket,with higher precision.customized special fixture. fixed workpiece with fast collet.perfectly applied for assembly balance

Technical data at a glance	PRZD-DSD
Max Mass of Workpiece(kg)	5
Balancing Speed(r/min)	200-700
Maximum Diameter of Workpiece(mm)	700-1300
Min Achievable Residual Unbalance Amount (emar)	5g· mm/kg
Unbalance Reduction Rate(%)	≥90
Working Voltage	AC220V
System	JP-380/JP-680
