5/16kg Belt Drive Balancing Machine

  • Specially designed brackets transmit mechanical force with low vibration damping
  • Durable and reliable sensor possesses good linearity
  • Permanent calibration brings high accuracy with a permission of large initial unbalance amount
  • Belt-driving offers higher precision and easier operation
  • Advanced electrical measuring system and friendly man-machine interface
  • Modular design offers a wide range of application
  • Technical Data
  • Gallery
  • Download
  • Video
  • Info Form
  • Applicable to small workpieces
    Technical data at a glance PHQ-1.6A/5A PHQ-16A
    Max Mass of Workpiece(kg) 1.6/5 16
    Max Diameter of Workpiece (mm) Φ300 Φ300
    Distance Between Two Support Bearings (mm) 60~500 60~500
    Journal Diameter Scope of Workpiece (mm) Φ 3~40 Φ 5~40
    Diameter Scope of Driving Belt (mm) Φ15~150 Φ15~150
    Rotational Speed when the Diameter of Driving Belt is 100mm (r/min)  ~1470 ~1470
    Motor Power (kw) 0.23DC 0.23DC
    Min Achievable Residual Unbalance Amount (emar) ≤0.15g· mm/kg ≤0.15g· mm/kg



    1) Stepless speed regulation
    2) Frequency conversion
    3) Can add to 75-180
    4Can add to 120-240
