Vertical milling automatic balancing machine

Flywheel, turntable, fan, clutch and other high-speed rotating motion body, due to its material quality, processing technology and assembly quality and other storage problems, there will inevitably be more or less uneven mass distribution, processing level deviating from the design value, and unexpected assembly gap. As a result, the inertia spindle located in the center of mass of the rotating body (mechanical rotor) does not coincide with the rotation axis represented by the actual rotation center, and there is a centrifugal force acting on the rotation axis during rotation, that is, dynamic unbalance.

Don't worry, Shanghai Jianping vertical milling automatic balancing machine is designed to solve your problem and improve your productivity.

Vertical milling automatic balancing machine product features

Workpiece from the unbalance measurement, angle positioning, milling & weight removal to retest are all implemented automatically, with features of high speed and high precision. Suitable for single or mass production of workpieces.

The vertical milling automatic balancing machine is suitable for brake disc, brake drum, impeller and other disc-shaped parts with a center hole or shaft, diameter φ200-φ600mm.

01 High precision, high efficiency, equipment working cycle time (initial test + milling + retest) up to 40 seconds, testing and milling at the same time;

02 Single-plane balancing, cylindrical surface or end face milling, quick changeover, parametric adjustment, simple operation, strong compatibility;

03 Can do single-machine automatic balancing, can connect automatic line for automatic production, can match with MES system, to achieve data traceability;

Testing unit

Test time is 6~10 seconds

Workpiece weight removal thickness 8-110mm

Min. achievable residual unbalance ≤1gmm/Kg

Milling angle 90-75 degrees

Vertical soft-bearing measurement

With protection, support quick changeover

Cutting & machining unit

Milling tool is used

Once weight reduction ratio > 90%

Residual unbalance is small

With chip removal device

The power source is servo motor, and the speed of milling tool is adjustable
